Automatic Tablet Counting Machine with 15,000 Tablets Per Minute, >99.98% Accuracy Rate, and 10~500ml Bottle Compatibility

Brand Name : LTPM CHINA

Model Number : LTEC-Series

Certification : CE

Place of Origin : Zhejiang China

MOQ : 1 Set

Price : Negotiable price

Delivery Time : 45 Days

Packaging Details : WOODEN CASE

Model : RC-2/HY-2/HY-2A/ LTEC-Series

Service : Door To Door Service

Air Consumption : ≤100L/min

Applicable Bottle : 10~500ml Round、square Plastic Bottle

Packing : Wooden Case

Filling Range : 2-9999 Pcs/bottle

Accuracy Rate : ＞99.98%

Capacity : Up To 15,000 Tablets Per Minute

Contact Now

Working Principle

Under the driving of the vibration, the product pass through the regulating valve below the material container, moving forward in order and fall into counting tunnels. When the product reaches raster holes, the counting photoelectric will produce a pulse signal and counting. The signal is grouped into the left and the right, accumulated and sent to the PLC. When the set quantity is reached, the flashboard will close.

At the same time, the bottle to be filled is already in its position. The funnel cylinder board opens, and the counted product fall into the bottle. Then the tunnel begins another counting, the positioning cylinder opens, and the filled bottle is sent to the next process. A new bottle is placed under the funnel, a new round of counting and filling starts.

Automatic Tablet Counting Machine with 15,000 Tablets Per Minute, >99.98% Accuracy Rate, and 10~500ml Bottle Compatibility
Key Features
  • Product Name: Tablet Counting Machine
  • Application: Tablets, Capsules, Pills, Candies, Screws, Nuts
  • Applicable Bottle: 10~500ml Round and Square Plastic Bottles
  • Counting Accuracy: ≥99.5%
  • Packing: Wooden Case
  • Location: China
Technical Specifications
Parameter Specification
Accuracy Rate >99.98%
Application Tablet, Capsules, Pills, Candies, Screws, Nuts
Air Consumption ≤100L/min
Filling Range 2-9999 Pcs/bottle
Pill Size 5-25mm
Model RC-2/HY-2/HY-2A/LTEC-Series
Service Door To Door Service
Packing Wooden Case
Location China
Applicable Bottle 10~500ml Round, square Plastic Bottle
Applications

Automatic Tablet Counting Machine with 15,000 Tablets Per Minute, >99.98% Accuracy Rate, and 10~500ml Bottle Compatibility

Machine Details
Automatic Tablet Counting Machine with 15,000 Tablets Per Minute, >99.98% Accuracy Rate, and 10~500ml Bottle Compatibility
